Buch, Englisch, 0 Seiten, Format (B × H): 156 mm x 235 mm, Gewicht: 794 g
Design of Flexure Hinges
Buch, Englisch, 0 Seiten, Format (B × H): 156 mm x 235 mm, Gewicht: 794 g
ISBN: 978-0-8493-1367-7
Verlag: Taylor & Francis Inc
Flexure hinges hold several advantages over classical rotation joints, including no friction losses, no need for lubrication, no hysteresis, compactness, capacity to be utilized in small-scale applications, ease of fabrication, virtually no assembly, and no required maintenance. Compliant Mechanisms: Design of Flexure Hinges provides practical answers to the present and future needs of efficient design, analysis, and optimization of devices that incorporate flexure hinges. With a highly original approach the text:Discusses new and classical types of flexure hinges (single-, two- and multiple-axis) for two- and three-dimensional applicationsAddresses a wide range of industrial applications, including micro- and nano-scale mechanismsQuantifies flexibility, precision of rotation, sensitivity to parasitic loading, energy consumption, and stress limitations through closed-form compliance equationsOffers a unitary presentation of individual flexure hinges as fully-compliant members by means of closed-form compliance (spring rates) equationsFully defines the lumped-parameter compliance, inertia and damping properties of flexure hinges Develops a finite element approach to compliant mechanisms by giving the elemental formulation of new flexure hinge line elementsIncorporates more advanced topics dedicated to flexure hinges including large deformations, buckling, torsion, composite flexures, shape optimization and thermal effectsCompliant Mechanisms: Design of Flexure Hinges provides practical answers and directions to the needs of efficiently designing, analyzing, and optimizing devices that include flexure hinges. It contains ready-to-use plots and simple equations describing several flexure types for the professional that needs quick solutions to current applications. The book also provides self-contained, easy-to-apply mathematical tools that provide sufficient guidance for real-time problem solving of further applications.
Zielgruppe
Engineers, researchers, and students in the and automotive, aerospace, MEMS, photonics and biomedical industries
Autoren/Hrsg.
Weitere Infos & Material
PrefaceINTRODUCTIONCOMPLIANCE-BASED DESIGN OF FLEXURE HINGESIntroductionGeneric Mathematical FormulationSingle-Axis Flexure Hinges for Two-Dimensional Applications Multiple-Axis Flexure Hinges for Three-Dimensional ApplicationsTwo-Axis Flexure Hinges for Three-Dimensional ApplicationsConclusions STATICS OF FLEXURE-BASED COMPLIANT MECHANISMSIntroductionPlanar Compliant MechanismsSpatial Compliant MechanismsDYNAMICS OF FLEXURE-BASED COMPLIANT MECHANISMSIntroductionElastic Potential Energy for Individual Flexure HingesKinetic Energy for Individual Flexure HingesFree and Forced Response of Flexure-Based Compliant MechanismsDamping EffectsFINITE ELEMENT FORMULATION FOR FLEXURE HINGES AND FLEXURE-BASED COMPLIANT MECHANISMSIntroductionGeneric FormulationElemental Matrices for Flexure HingesElemental Matrices for Rigid LinksApplication ExampleAppendixTOPICS BEYOND THE MINIMAL MODELING APPROACH TO FLEXURE HINGESLarge DeformationsBucklingTorsion of Noncircular Cross-Section Flexure HingesComposite Flexure HingesThermal EffectsShape OptimizationMeans of ActuationFabricationAPPLICATIONS OF FLEXURE-BASED COMPLIANT MECHANISMSMacroscale ApplicationsMicroscale (MEMS) Applications
