Voyiadjis Advances in Damage Mechanics: Metals and Metal Matrix Composites

1. Auflage 2012
ISBN: 978-0-08-091303-2
Verlag: Elsevier Science & Techn.
Format: EPUB
Kopierschutz: 6 - ePub Watermark

E-Book, Englisch, 541 Seiten

This book provides in a single and unified volume a clear and thorough presentation of the recent advances in continuum damage mechanics for metals and metal matrix composites. Emphasis is placed on the theoretical formulation of the different constitutive models in this area, but sections are added to demonstrate the applications of the theory. In addition, some sections contain new material that has not appeared before in the literature. The book is divided into three major parts: Part I deals with the scalar formulation and is limited to the analysis of isotropic damage in materials; Parts II and III deal with the tensor formulation and is applied to general states of deformation and damage. The material appearing in this text is limited to plastic deformation and damage in ductile materials (e.g. metals and metal matrix composites) but excludes many of the recent advances made in creep, brittle fracture, and temperature effects since the authors feel that these topics require a separate volume for this presentation. Furthermore, the applications presented in this book are the simplest possible ones and are mainly based on the uniaxial tension test.

Dr. Voyiadjis is a Member of the European Academy of Sciences, and Foreign Member of both the Polish Academy of Sciences, and the National Academy of Engineering of Korea. George Z. Voyiadjis is the Boyd Professor at the Louisiana State University, in the Department of Civil and Environmental Engineering. This is the highest professorial rank awarded by the Louisiana State University System. He is also the holder of the Freeport-MacMoRan Endowed Chair in Engineering. He joined the faculty of Louisiana State University in 1980. He is currently the Chair of the Department of Civil and Environmental Engineering. He holds this position since February of 2001. He also served from 1992 to 1994 as the Acting Associate Dean of the Graduate School. He currently also serves since 2012 as the Director of the Louisiana State University Center for GeoInformatics (LSU C4G; http://c4gnet.lsu.edu/c4g/ ).Voyiadjis' primary research interest is in plasticity and damage mechanics of metals, metal matrix composites, polymers and ceramics with emphasis on the theoretical modeling, numerical simulation of material behavior, and experimental correlation. Research activities of particular interest encompass macro-mechanical and micro-mechanical constitutive modeling, experimental procedures for quantification of crack densities, inelastic behavior, thermal effects, interfaces, damage, failure, fracture, impact, and numerical modeling. Dr. Voyiadjis' research has been performed on developing numerical models that aim at simulating the damage and dynamic failure response of advanced engineering materials and structures under high-speed impact loading conditions. This work will guide the development of design criteria and fabrication processes of high performance materials and structures under severe loading conditions. Emphasis is placed on survivability area that aims to develop and field a contingency armor that is thin and lightweight, but with a very high level of an overpressure protection system that provides low penetration depths. The formation of cracks and voids in the adiabatic shear bands, which are the precursors to fracture, are mainly investigated. He has two patents, over 332 refereed journal articles and 19 books (11 as editor) to his credit. He gave over 400 presentations as plenary, keynote and invited speaker as well as other talks. Over sixty two graduate students (37 Ph. D.) completed their degrees under his direction. He has also supervised numerous postdoctoral associates. Voyiadjis has been extremely successful in securing more than $30.0 million in research funds as a principal investigator/investigator from the National Science Foundation, the Department of Defense, the Air Force Office of Scientific Research, the Department of Transportation, National Oceanic and Atmospheric Administration (NOAA), and major companies such as IBM and Martin Marietta.
